Universal Rod Ends Inch Female Stainless 304 Housing, PTFE Race 10-32 RH 10 Pack Quantity Per Package: This package includes 10 Spherical Rod Ends Product Name: Female Spherical Rod End Thread: Female 10-32 RH x 0.562 Ball ID: 3/16 inch Housing Material: 300 Series Stainless Steel Bearing Race: PTFE Housing Width: 0.625 inch Base of Rod End to Center of Ball: 1.062 inch Ball Thickness: 0.312 inch Ultimate Static Load Rating: 1361 lbs Common Other Names for this Product: heim joint, rose joint, Gelenkköpfe, Rotula Esféfico, Embouts, Teste a snodo Application: Our larger chrome moly Spherical Rod Ends are used as sway bar end links, panhard bars, control arms, three link and four link suspensions and strut tower braces. This size rod end is often used in hand or foot actuated push-pull linkages.

Common Accessories:
These Spherical Rod Ends are typically used with our WTF-M thread bungs, MHTconnecting tubes, male Spherical Rod Ends, jam nuts, and bolts.

Alternative Designs:
For lighter duty linkage applications, consider our ASFM (steel raced) series, our DXTF (nylon) series, DSTF (stainless) series, or DPF (bronze zerked) series.

Warning:
Regardless of a specific product's name or marketing description, rod ends used in the wrong application will fail. We encourage our customers to know the load rating requirements of their application.
