Setrab ProLine COM range oil coolers offer unique & versatile plumbing opportunities in a heavy-duty high-performance build. The design of the COM cooler allows for a wider cooler than standard, and the end tanks feature a heavier build. Setrab ProLine oil coolers feature M22 female ports, adaptable to virtually any size using SUSA ProLine Adapter Fittings. (fittings and plugs* sold separately) *Setrab 52-12864-01 has four (x4) M22x1.5 female ports to offer greater variety in plumbing orientation. This means it requires two (x2) 22-M22 plugs to block off the unused ports.

Specifications Ports:
M22 ProLine (22mm x 1.5 female thread) Max connection tightening torque: 40Nm (29.5 ft/lbs) Mounting Bungs: M8x1.5 Material: Aluminum Color: Black Working Pressure: 0-16 Bar Dynamical Max Pressure: 25 Bar @ 10,000 Pulses Burst Pressure: 50 Bar Working Temp: -40 to 150 °C Inner Cleanliness: ISO 4406 16/14 (alternative available upon request) General Dimensional Tolerance: ISO 2768-v Fluid Compatibility: Oil; water containing min. 40% glycol or corrosion inhibitors. Notes Setrab COM ProLine oil coolers are to be mounted securely and isolated from vibration and flex. We recommend and offer size-specific mounting bracket kits for this reason, though custom brackets and mounting solutions may be used so long as the previously noted conditions are met. The size of a cooler is dependent on system requirements. If you are unsure what size cooler you may need. Please use our contact page for a system consultation. Mounting and placement of the cooler are essential to its success. Size of lines is dependent on the cooling application: transmissions usually use -06 or -08, engine oil coolers commonly use -10 or -12 but could use size -06 to -16 depending on oil flow. Fitment Universal
- Non-Specific. Setrab ProLine STD oil coolers are used across the world in automotive and industrial applications. If you are looking for a direct replacement, please refer to the Part Number label on the top plate of the cooler. The determined size of an oil cooler is dependent on the heat rejection requirements for a system. If you need assistance with the selection of a size, please use our contact page for a consultation. Please refer to the Oil Cooler Page for recommended coolers and information on flow and heat rejection expectations as it may apply to your system.
