Bilstein 33-230412 B8 5125 - Suspension Shock Absorber
1 / 2
Bilstein 33-230412 B8 5125 - Suspension Shock Absorber
MPN: 33-230412UPC: 00651860729305In Stock
Only 6 left in stock - order soon! $118.00$168.10SAVE 30%
Starting at $10/mowithaffirm
KBOA Lifted Truck 5125 Series 236.5mm
KBOA Lifted Truck 5125 Series 236.5mm
Technical Specifications
| Length | 26.8000 in |
| Width | 2.9500 in |
| Height | 2.9500 in |
| Part Number | 33-230412 |
| UPC | 00651860729305 |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Damping | Non-Adjustable |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Body Design | Smooth Body (Non-Coilover) |
| Boot Included | Black Bellows |
| Collapsed Length (IN) | 15.19 |
| Collapsed Length (MM) | 385.8 |
| Compressed Length | 15.19 IN |
| Compression @0.52m/s | 755 |
| Country of Origin | MX |
| Emissions | Emissions Compliance Exempt |
| Extended Length | 620.0 MM |
| Extended Length (IN) | 24.41 |
| Extended Length (MM) | 620.0 |
| Finish | Zinc Plated |
| Grade Type | Performance |
| Height | 2.9500 |
| Height (in) | 2.95 |
Installation Overview
Difficulty
🔧🔧🔧🔧⚪
Advanced
Common Tools: Floor jack, Jack stands, Socket set, Torque wrench, Spring compressor
