7100 CLASSIC SERIES 46MM MONOTUBE SHOCK ABSORBER (VW KIT) USE: OPTIONAL B4-BOA-0000117 COILOVER KIT
1 / 2
7100 CLASSIC SERIES 46MM MONOTUBE SHOCK ABSORBER (VW KIT) USE: OPTIONAL B4-BOA-0000117 COILOVER KIT
MPN: F4-B46-0930-H0UPC: 00790832511873In Stock
$177.00$181.42SAVE 2%
Starting at $15/mowithaffirm
7100 CLASSIC SERIES 46MM MONOTUBE SHOCK ABSORBER (VW KIT) USE: OPTIONAL B4-BOA-0000117 COILOVER KIT
7100 CLASSIC SERIES 46MM MONOTUBE SHOCK ABSORBER (VW KIT) USE: OPTIONAL B4-BOA-0000117 COILOVER KIT
Technical Specifications
| Length | 21.4500 in |
| Width | 2.9500 in |
| Height | 2.9500 in |
| Part Number | F4-B46-0930-H0 |
| UPC | 00790832511873 |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Body Design | Smooth Body (Coilover) |
| Collapsed Length (IN) | 11.24 |
| Collapsed Length (MM) | 285.5 |
| Compressed Length | 11.24 IN |
| Compression @0.52m/s | 1600 |
| Country of Origin | US |
| Emissions | Emissions Compliance Exempt |
| Extended Length | 412.5 MM |
| Extended Length (IN) | 16.24 |
| Extended Length (MM) | 412.5 |
| Finish | Zinc Plated |
| Grade Type | Performance |
| Height | 2.9500 |
| Height (in) | 2.95 |
| Installation Instructions | https://sdda.semadata.org/Standard/Thyssen Krupp Automotive Group/Generic_instructions_02.pdf |
| Internal Design | Monotube |
Installation Overview
Common Tools: Floor jack, Jack stands, Socket set, Torque wrench, Spring compressor
